High-quality aluminum alloy sheet, plate, round tube, and square tube for industrial fabrication. Grades 1050, 1060, 1100, 2024, 3003, 5052, 5083, 6061, 6063, 6082, and 7075. Compliant with GB/T 3880, ASTM B209, EN 485. Mill test certificates available.
| Grade | Series | Key Properties | Common Applications | Standards |
|---|---|---|---|---|
| 1050 | 1xxx (Pure) | Excellent corrosion resistance, high ductility, good electrical conductivity | Chemical equipment, food industry, reflectors, nameplates | GB/T 3880, ASTM B209, EN AW-1050 |
| 1060 | 1xxx (Pure) | High thermal/electrical conductivity, excellent workability | Electrical bus bars, chemical tanks, heat exchangers | GB/T 3880, ASTM B209, EN AW-1060 |
| 1100 | 1xxx (Pure) | Good formability and weldability, moderate strength | Sheet metal work, spun hollowware, fin stock, food containers | GB/T 3880, ASTM B209, EN AW-1100 |
| 2024 | 2xxx (Al-Cu) | High strength, excellent fatigue resistance, machinable | Aerospace structures, wing skin, truck wheels, screw machine parts | ASTM B209, AMS 4037, EN AW-2024 |
| 3003 | 3xxx (Al-Mn) | Good corrosion resistance, moderate strength, excellent formability | Cooking utensils, chemical equipment, storage tanks, roofing sheets | GB/T 3880, ASTM B209, EN AW-3003 |
| 5052 | 5xxx (Al-Mg) | Good fatigue strength, excellent seawater corrosion resistance | Marine components, fuel tanks, pressure vessels, electronic enclosures | GB/T 3880, ASTM B209, EN AW-5052 |
| 5083 | 5xxx (Al-Mg) | Excellent marine corrosion resistance, high strength, weldable | Shipbuilding, offshore platforms, rail cars, pressure vessels | GB/T 3880, ASTM B209, EN AW-5083 |
| 6061 | 6xxx (Al-Mg-Si) | Versatile, heat-treatable, good corrosion resistance, weldable | Structural components, truck & marine frames, pipelines, bridges | GB/T 3880, ASTM B209, EN AW-6061 |
| 6063 | 6xxx (Al-Mg-Si) | Excellent extrudability, good surface finish, corrosion resistant | Architectural extrusions, window/door frames, railings, furniture | GB/T 5237, ASTM B221, EN AW-6063 |
| 6082 | 6xxx (Al-Mg-Si) | Higher strength than 6061, good corrosion resistance, machinable | Structural beams, bridges, trusses, transport applications | GB/T 3880, ASTM B209, EN AW-6082 |
| 7075 | 7xxx (Al-Zn) | Very high strength, good fatigue resistance, machinable | Aerospace, defense, mold tooling, high-stress structural parts | ASTM B209, AMS 4045, EN AW-7075 |
| Dimension | Range |
|---|---|
| Thickness (Sheet) | 0.3 – 6.0 mm |
| Thickness (Plate) | 6.0 – 200 mm |
| Width | 1000 / 1200 / 1250 / 1500 / 2000 mm |
| Length | 2000 / 2400 / 2500 / 3000 / 6000 mm |
| Custom Sizes | OEM cutting to specification |
| Dimension | Range |
|---|---|
| Round Tube OD | 6 – 200 mm |
| Round Tube Wall | 0.5 – 8.0 mm |
| Square Tube | 10×10 – 100×100 mm |
| Rectangular Tube | 20×10 – 150×100 mm |
| Custom Profiles | OEM extrusion available |
| Temper | Description |
|---|---|
| O | Annealed (softest, maximum formability) |
| H12 | Strain hardened — 1/4 hard |
| H14 | Strain hardened — 1/2 hard |
| H16 | Strain hardened — 3/4 hard |
| H18 | Strain hardened — full hard |
| H22 | Strain hardened & partially annealed |
| H32 | Strain hardened & stabilized |
| T4 | Solution heat-treated & naturally aged |
| T5 | Cooled from elevated temp & artificially aged |
| T6 | Solution heat-treated & artificially aged |
| T651 | T6 + stress relieved by stretching |
| Finish | Description |
|---|---|
| Mill Finish | As-rolled surface, standard industrial finish |
| Anodized (Clear) | Clear anodized coating — corrosion & wear resistant |
| Anodized (Color) | Black, gold, red, blue, green, silver — architectural grade |
| Brushed | Uniform brushed grain — decorative applications |
| Polished | Bright mirror finish — automotive trim, lighting |
| Coated (PVDF) | Fluorocarbon paint — exterior architectural, high UV resistance |
| Coated (Polyester) | Powder coating — RAL colors available |
| Stucco / Embossed | Textured surface — anti-slip flooring |
| Perforated | Custom hole patterns — acoustic panels, filtration |
| Checkered (Tread) | Diamond or bar pattern — flooring, steps |
| Product | HS Code |
|---|---|
| Aluminum plate/sheet (≤ 0.2mm) | 7606.11 |
| Aluminum plate/sheet (> 0.2mm) | 7606.12 |
| Aluminum round tube | 7608.10 |
| Aluminum square/rectangular tube | 7608.20 |
| Aluminum bar & rod | 7604.29 |
| Aluminum anodized sheet | 7606.91 |
| Standard | Scope |
|---|---|
| GB/T 3880 | China — Wrought aluminum alloy sheet/plate |
| GB/T 4437 | China — Aluminum alloy seamless tube |
| ASTM B209 | USA — Aluminum alloy sheet/plate |
| ASTM B210 | USA — Aluminum drawn seamless tube |
| ASTM B221 | USA — Aluminum extruded bar/rod/tube |
| EN 485 | Europe — Aluminum sheet/plate (general engineering) |
| EN 573 | Europe — Aluminum chemical composition & tempers |
| JIS H4000 | Japan — Aluminum sheet/plate |
| JIS H4080 | Japan — Aluminum seamless tube |
Aluminum products for manufacturing, construction, transportation, and marine applications.
5083 marine-grade plate for hulls, 6061 for deck structures, 5052 for fuel tanks. Corrosion-resistant materials in saltwater environments.
2024 and 7075 high-strength aluminum for aircraft structural components, defense equipment, and spacecraft parts. AMS certified.
6063 architectural extrusions for curtain walls, window frames, handrails. PVDF-coated for long-term outdoor performance.
Body panels, heat shields, fuel tanks, truck frames. 5xxx and 6xxx series for lightweight vehicle manufacturing.
1050 and 1060 for heat sinks, bus bars, LED housings, electronic enclosures. High thermal and electrical conductivity.
Pressure vessels, chemical tanks, food processing equipment, storage silos. Weldable grades with certified material properties.
Get a customized quote with shipping to your port. Our sales engineers respond within 24 hours.
