Handheld fiber laser welding machine for carbon steel, stainless steel, aluminum, galvanized sheets, and copper. Replace traditional argon arc welding — faster, cleaner, and more precise. CE certified.
| Parameter | Specification |
|---|---|
| Laser Power | 1000W / 1500W / 2000W / 3000W |
| Laser Source | Raycus / Maxphotonics (fiber laser) |
| Weldable Materials | Carbon steel, stainless steel, aluminum, galvanized steel, copper, brass |
| Welding Speed | 0 – 120 mm/s (adjustable) |
| Wire Feeding Diameter | 1.0 – 1.6 mm |
| Max Penetration Depth (1000W) | Carbon Steel: 3mm · Stainless Steel: 2.5mm · Aluminum: 2mm |
| Max Penetration Depth (2000W) | Carbon Steel: 4.5mm · Stainless Steel: 3.5mm · Aluminum: 3mm |
| Max Penetration Depth (3000W) | Carbon Steel: 6mm · Stainless Steel: 5mm · Aluminum: 4mm |
| Welding Gap Tolerance | ≤ 1.5 mm |
| Welding Mode | Continuous / Pulse / Spot welding |
| Fiber Length | 10m / 15m / 20m (optional) |
| Cooling System | Industrial water chiller (dual temperature control) |
| Power Supply | 220V / 380V 50/60Hz |
| Certification | CE, FDA, ISO 9001:2015 |
Ergonomic handheld welding torch with intuitive controls. Operators can weld in any position — flat, vertical, horizontal, overhead. Minimal training required.
Weld carbon steel, stainless steel, aluminum, galvanized sheets, copper, and brass. No need for multiple machines or processes.
3-5x faster than traditional TIG welding. Less heat input means minimal distortion. No filler rod required for thin materials. Cleaner welds with less post-processing.
Automatic wire feeding system (1.0-1.6mm diameter). Precise feeding speed control for consistent weld quality across long seams.
Class 1 laser enclosure. Safety interlock, emergency stop, over-temperature protection. Laser shielding glass included. CE & FDA CDRH compliant.
Wheeled cabinet design — move easily between workstations. Compact footprint saves valuable shop floor space. Optional battery pack for field repair work.
Versatile laser welding for precision metal joining across multiple industries.
Stainless steel sink welding, kitchen appliance assembly, cookware handles and rims — clean, food-grade welds with no porosity.
Aluminum and stainless steel door/window frame welding. Corner joints, miter joints, and structural reinforcement. Strong, visually seamless welds.
Body panel repair, exhaust system patching, frame reinforcement. Portable enough for on-site auto body shop use. Works on galvanized and coated panels.
Enclosures, cabinets, ventilation ducts, machine guards. Fast thin-gauge welding without burn-through. Excellent for 0.5-3mm sheet metal work.
Metal letter welding, sign frames, display stands, channel letter fabrication. Precision welds for exposed decorative applications.
Handrails, balustrades, architectural fittings, food processing equipment. No discoloration or oxide formation — reduces grinding and polishing time.
Get a customized quote with shipping to your port. Our sales engineers respond within 24 hours.
